The LEITZ PRIME lenses



The 13 focal lengths from 18 mm to 350 mm in the set of LEITZ PRIME full frame cine lenses carry the name LEITZ with its exceptional heritage for a reason. They are the best of the best when it comes to their fast T1.8 aperture (180 mm T2, 350 mm T3.6), minimal breathing, exceptionally low distortion, and non-visible chromatic aberration.



With a consistent high resolution and illumination across the entire frame and a smooth focus roll off, the LEITZ PRIME lenses present a clean image to build any looks on and are well-suited for VFX, virtual production, and post production as well.



The LEITZ PRIME lenses colour match with the LEITZ ZOOM lenses, therefore making them a perfect set for all production needs. With a 114 mm front diameter you can also make use of the MACROLUX 114 diopters. The LEITZ PRIME lenses are available in PL and LPL mount with Cooke/i and LDS-2 metadata contacts.







Leitz Prime 18mm horizontal left

Shot with LEITZ PRIME

Check out these short films that were all shot on our LEITZ PRIME Lenses

Hennessy V.S.O.P – Enter the Show

Mercedes Benz E-Class 2020 China

A Holiday Reunion Xfinity 2019

Technical Specifications

Focal Length (mm)

18 mm

21 mm

25 mm

29 mm

35 mm

40 mm

50 mm

65 mm

75 mm

100 mm

135 mm

180 mm

350 mm

Aperture

T1.8

T1.8

T1.8

T1.8

T1.8

T1.8

T1.8

T1.8

T1.8

T1.8

T1.8

T2

T3.6

Image Circle

46.5 mm

Close Focus (ft)

1’2”

1’10”

1’10”

1’2”

1’6”

1’2”

1’7”

2’2”

2’2”

3’11”

3’11”

4’11”

9'10"

Close Focus (m)

0.35

0.55

0.55

0.35

0.45

0.35

0.47

0.65

0.75

1.2

1.2

1.5

3

Horizontal angle of view “Full Frame” 36 mm x 24 mm

90.0°

81.2°

71.5°

63.7°

54.4°

48.5°

39.6°

31.0°

27.0°

20.4°

15.2°

11.4°

5.9°

Horizontal angle of view “Super 35” 24.9 mm x 18.7 mm

69.3°

61.3°

52.9

46.5°

39.1°

34.6°

28.0°

21.7°

18.8°

14.2°

10.5°

7.9°

4.1°

Weight (lb)

7.1

6.1

6.2

5.9

6.3

6.0

6.0

6.1

6.2

6.1

6.4

6.8

9.7

Weight (kg)

3.2

2.76

2.8

2.67

2.87

2.71

2.7

2.78

2.83

2.77

2.89

3.1

4.4

Length (in/mm)

7.9" / 201.5

7.2" / 183.7

7.2" / 183.7

7.2" / 183.7

7.2" / 183.7

7.2" / 183.7

7.2" / 183.7

7.2" / 183.7

7.2" / 183.7

7.2" / 183.7

7.2" / 183.7

7.9" / 201.5

12.5" / 317

Lens Mount

PL, LPL with Cooke/i

Front Diameter

114 mm

Front Filter | Rear Filter

M 112 mm x 1.5 mm screw-in | Via net holder

Matched Focus/Iris Ring Locations

All focal lengths

Focus Rotation | Iris Rotation

270° (except 18 mm 207°) | 66° (except 180 mm 63°; 350 mm 49°)

Focus Scales

Turnable scales, easy change from imperial to metric

Iris Blades | Iris Shape

15 Blades (except 350 mm 21 Blades) | Circular through all stops

Color Matching

Matched with LEITZ ZOOM lenses

Extras

Stepdown 114 95mm seperate

MACROLUX 114
