The Leitz ELSIE lenses are designed for full frame performance with a consistency in size and speed to serve a broad range of productions. The 13+ lens set ranges from 15 mm to 150 mm, all at T2.1.



Designed and produced in Germany, the ELSIE lenses incorporate the warmth and resolution that Leitz lenses are known for, yet they feature a noticeable but gradual falloff of resolution and illumination as the image approaches the corners to create a dimensional pop that gently draws the viewer‘s eye toward the center of the frame.





ELSIE 25 mm horizontal right
ELSIE 25 mm straight name

Made in Germany

Designed and manufactuered in Germany, the ELSIE lenses incorporate the warmth and resolution that Leitz lenses are known for.





L1000231 ELSIE 25mm T2.1 FDTimes

Bokeh Design

A new bokeh design developed in conjunction with Leica Camera more closely mimics their M lenses by creating out-of-focus elements that are painterly while still being recognizable.

ELSIE 25 mm straight

Consistent T-Stop

All the ELSIE lenses are at T2.1. They are designed for full frame performance with a consistency in size and speed to serve a broad range of productions.

Technical Specifications

Focal Length

15 mm

18 mm

21 mm

25 mm

29 mm

35 mm

40 mm

50 mm

65 mm

75 mm

100 mm

125 mm

150 mm

Aperture

T2.1

T2.1

T2.1

T2.1

T2.1

T2.1

T2.1

T2.1

T2.1

T2.1

T2.1

T2.1

tba

Image Circle

46.5 mm

Close Focus (ft)

1'2"

1'2"

1'2"

1'2"

1'2"

1'2"

1'2"

1'8"

2'2"

2'6"

2'10"

4'2"

5'

Close Focus (m)

0.35

0.35

0.35

0.35

0.35

0.35

0.35

0.5

0.65

0.75

0.85

1.25

1.5

Horizontal angle of view "Full Frame" 36 mm x 24 mm

100.4°

90°

81.2°

71.5°

63.7°

54.4°

48.5°

39.6°

31°

27°

20.4°

16.4°

tba

Horizontal angle of view "Super 35" 24.9 mm x 18.7 mm

79.4°

69.3°

61.3°

59.2°

46.5°

39.1°

34.6°

28°

21.7°

18.8°

14.2°

11.4°

tba

Weight (lb)

tba

5.3

5.3

4.4

4.4

4.4

4.4

4.4

4.4

4.6

4.6

5.5

tba

Weight (kg)

tba

2.4

2.4

2

2

2

2

2

2

2.1

2.1

2.5

tba

Length (in / mm)

tba

6.3" / 160

6.3" / 160

6.3" / 160

6.3" / 160

6.3" / 160

6.3" / 160

6.3" / 160

6.3" / 160

6.3" / 160

6.3" / 160

6.3" / 160

tba

Lens Mount

LPL with Cooke/I and LDS-2

Front Diameter

tba

114 mm

114 mm

95 mm

95 mm

95 mm

95 mm

95 mm

95 mm

95 mm

95 mm

114 mm

tba

Front Filter | Rear Filter

M 92 mm x 1 mm screw-in: 25 mm - 100 mm; M 112 x 1.5 screw: 125 mm | Via Net Holder

Matched Focus/Iris Ring Locations

All focal lengths

Focus Rotation | Iris Rotation

270° | 51.45°

Focus Scales

Turnable scales, easy change from imperial to metric

Iris Blades

tba

15 Blades

15 Blades

15 Blades

tba

13 Blades

13 Blades

tba

tba

13 Blades

13 Blades

tba

tba

Iris Shape

Circular through all stops

Extras

Stepdown 114 95mm seperate

MACROLUX 114

Learn more
Macrolux 2 1 1

MACROLUX 95

Learn more
L to PL und L to LPL Adapter edit

L to PL | L to LPL

Learn more
